REPAIR PARTS
Ref Part Number Description Qty
Serial
Number
7 144833 ROLLER – IDLER WELDMENT 1
8 144494 ROLLER – DRIVE WELDMENT 1
9
144501
ARM – SUPPORT
1
10
144499
ARM – ROLLE R SUPPORT
1
11
176000
ARM – SUPPORT WELDMENT
1
12 144837 ARM – SUPPORT REAR 1
13 165735 PIN ASSEMBLY – DRAPER ROLLER 3
14 30441 WASHER – H ARDENED 3
15 145249 BOLT – HEX HEAD, 5/8 N F x 1.0 LG GR 5 ZP 3
16 172259 BOLT – SHOULDER, 3/8-16 UNC 4
144832 MOTOR – HYDRAULIC M & S 1.52 CI 1
17
132759 SEAL KIT – M & S MOTOR
18 18709 SETSCREW – HEXHD, SKT CUP PT 3/8 NC x 5/8 LG 2
19 18664 NUT – HEX JAM, 3/8-16 UNC GR 5 ZP 2
20 120845 SEAL – NILOS LSTO STEEL DISK 3
21 145249 BOLT – HEX HEAD, 5/8 N F x 1.0 LG GR 5 ZP 3
22 30441 WASHER – H ARDENED 3
23 145593 ROD – ADJUSTER WELDMENT 1
24 145345 ROD – ADJUSTER WELDMENT 1
28 144602 PANEL – REAR WELDMENT 1
29 172747 SKID – COMPLETE WITH REFLECTORS 1
30 115145 REFLECTOR – F LUORESCENT R ED-OR ANGE 1
31 115147 REFLECTOR – RED 1
32 145357 BRACKET – IDLER ARM 1
38 144652 BAR – STIFFENER 1
39 144851 DEFLECTOR – SEAL 1
40 144558 BUSHING – STEEL 1
41 144597 SEAL – BACKSHEE T 1
42 165304 DRAPER – ENDLE SS, DWA 1
44 37687 MOULDING 2
46 18598 WASHER – SAE FLAT, 13/32 ID x 13/16 INCH OD ZP 2
47 19966 BOLT – RDH, SQ NECK, 3/8 NC x 1.25 LG GR 5 ZP 1
48 18604 PIN – COTTER 3/32 DIA. x 3/4 ZP 1
214049 83 Revision A
