REPAIR PARTS
Ref Part Number Description Qty
Serial
Number
4 172746 ARM – DECAL ASS
EMBLY
1
5 174683
DECAL – WARNING DWA LIN KAGE PINCH POINT, 2
PANEL 2
8
144592
ARM – FRONT WELDMENT
1
9
144593
ARM – BOTTO
M WELDMEN T 1
10
144594
CLEVIS – WELDMENT
1
11 172910 SHAFT 1
12 176018 SHAFT 1
14 176023 SHAFT 1
16 109699 SWITCH – SNAP ACTION 1
17 11084
5
HARNE
SS – DWA
1
18 208966 CYLINDER – HYDRAULIC 1
176031 SEAL KIT – FOR CYLINDER
19 172
664
CLE
VIS
1
20 144996 JOINT ASSEMBLY 1
28 30816 BOLT – RHSN, 5/8 NC x 5 TFL GR 5 ZP 1
3
0
1
8592
N
UT–HEX,5/8-11UNCGR5ZP
2
31 176009 WASHER – NORDLOCK, 3/4" SP 4
32 30512 BOLT – HEX HEAD, 3/4 NC x 2.0 LG GR 5 ZP 4
36 18626 PIN – CLEVIS 1
37 18648 PIN – COTTER, 3/16 DIA. x 1.25 ZP 4
38 20312 PIN – CLEVIS 1
39 18627 PIN – CLEVIS 2
41 21354 BOLT – HEX HEAD, 3/8 NC x 2.0 LG GR 5 ZP 4
42 22072 WASHER – FLAT 1
43 30228 NUT – FLANGE, DT, SMOOTH FACE, 3/8-16 UNC 5
44 21484 BOLT – RHSN, 3/8 NC x 1.25 LG GR 5 ZP 1
45 135158 SCREW – PAN HEAD, #6-32 x 3/4 LG 2
46 135159 NUT – NYLOC 2
