215620 187 Revision A
Figure 5.147: Left Cab-Forward Platform
3. Push latch (A) to unlock platform (B).
Figure 5.148: Left Cab-Forward Platform
4. Pull platform (A) towards the cab until it stops and the latch
is engaged.
5. If necessary, calibrate both the knife drive and header position sensors on the windrower. Calibrate both the knife
drive and header position sensors whenever you are:
• Attaching the header to the windrower for the first time
• Changing the speed sensor or hydraulic drive motor on the header
• Changing the header drive pump associated with the knife drive, Harvest Performance Tracker (HPT), or the master
controller on the windrower
For instructions, refer to 5.7.1 Calibrating Knife Drive on Harvest Performance Tracker Display, page 230 and 5.7.2
Calibrating Header Position Sensors on Harvest Performance Tracker Display, page 233 .
ATTACHING A HEADER TO THE WINDROWER
