Figure 1.17: Cab Connectors
NOTE:
To disconnect the remaining circular Deutsch connectors, rotate
the outer collar counterclockwise.
• Cab connectors (A)
Two round connectors: C1 and C2
Location: Under the cab
Figure 1.18: Roof Connectors
• Roof connectors (A)
Four connectors: C10, C12, C13, and C14
Location: Under the cab at the base of the left cab post
Figure 1.19: Chassis Relay Module
• Chassis relay module (A)
Three connectors: P240, P241, and P242
Location: Outside the left frame rail near the batteries
