IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-29
C05-13 I/T Level 05 Current/Torque values detected during LC
set up for Zone 05
0–250% 0
C05-14 I/T Level 06 Current/Torque values detected during LC
set up for Zone 06
0–250% 0
C05-15 I/T Level 07 Current/Torque values detected during LC
set up for Zone 07
0–250% 0
C05-16 I/T Level 08 Current/Torque values detected during LC
set up for Zone 08
0–250% 0
C05-17 I/T Level 09 Current/Torque values detected during LC
set up for Zone 09
0–250% 0
C05-18 I/T Level 10 Current/Torque values detected during LC
set up for Zone 10
0–250% 0
C05-19 I/T Level 11 Current/Torque values detected during LC
set up for Zone 11
0–250% 0
C05-20 I/T Level 12 Current/Torque values detected during LC
set up for Zone 12
0–250% 0
C05-21 I/T Level 13 Current/Torque values detected during LC
set up for Zone 13
0–250% 0
C05-22 I/T Level 14 Current/Torque values detected during LC
set up for Zone 14
0–250% 0
C05-23 I/T Level 15 Current/Torque values detected during LC
set up for Zone 15
0–250% 0
C05-24 I/T Level 16 Current/Torque values detected during LC
set up for Zone 16
0–250% 0
C05-25 LC Integral Time Integral time used to smooth transitions 0.00–2.55 sec 0.05
C05-26 LC Delay Time Load Check delay time for transitions 0.00–2.55 sec 0.25
C05-27 Min I->Fwd Tim Minimum delay when switching from REV
to FWD in LC. Used when the load brake
cannot stop the load fast enough.
Setting of 0.0 disables delay triggering
timer
0.0–25.5 sec 0.0
C05-28 Dly Trig Freq Minimum frequency that will trigger C05-
27 timer
0.0–60.0 Hz 30.0
