IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-69
Factory setting is 230 (230V units) or 460 (460V units).
When E01-11 = 0, then the value of E01-11 is not used.
When E01-12 = 0, then the value of E01-12 is not used.
When E01-13 = 0, then the value of E01-13 is not used.
An OPE10 error will occur if the following conditions are not met:
E01-05 E01-12 E01-13 E01-08 E01-10
E01-04 E01-11 E01-06 E01-07 E01-09
NOTE: When using the Flex Vector control method, the V/f pattern voltage values will be adjusted
by the Auto-Tuning function.
The setting E01-01 sets the maximum and base voltage used by preset V/f patterns (E01-03 = 0 to
E), and adjusts the levels of drive protective features (e.g. Overvoltage, braking resistor turn-on, stall
prevention, etc).
Table 5-55: DC Bus Regulation
Inverter
Voltage
E01-01
Setting
Overvoltage Trip Braking Transistor
Stall Level
Trip Reset On Off
230 155–255 410 V 380V 380V 375V 380V
460 400 820 V 760V 760V 750V 760V
460 <400 740 V 680V 660V 650V 670V
575 500 V 1040 V 990V 990V 970V 960V
575 <500 V 990 V 940V 860V 840V 830V
Parameter E01-01 performs the above mentioned function in all three control methods.
