IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-70
Table 5-56:V/f Parameters
Parameter Display Function Range Default
E01-03 V/f Selection Motor V/f selection V/f: 0–9, A–F, FF
OLV: F, FF
*
0 60 Hz, Level 0 (Default for A01-03 = 0 (Traverse),
A01-03 = 4 (Braketronic))
1 60 Hz, Level 1
2 60 Hz, Level 2
3 60 Hz, Level 3
4 60 Hz, Level 4 (Default for A01-03 = 1 (Std Hoist))
5 60 Hz, Level 5
6 60 Hz, Level 6
7 60 Hz, Level 7
8 60 Hz, Level 8
9 50 Hz, Level 0
A 50 Hz, Level 2
B 50 Hz, Level 4
C 50 Hz, Level 6
D 75 Hz, Level 4
E 90 Hz, Level 4
FCustom V/f E01-04 through E01-13 settings
define the V/f pattern, (Default for
A01-03 = 2 (Hoist NLB)). When
A01-03 = 0, 1, 3, or 4 and E01-03
is changed to 0F, the values for
E01-04 through E01-13 are the
same as E01-03 = 4. See V/f
tables for appropriate voltage.
FF Custom w/o limit Custom with no lower limits on
E01-xx.
E01-04 Max Frequency Maximum Frequency 40.0–150.0 Hz 60.0
E01-05 Max Voltage Maximum Voltage 230 V: 0.0–255.0
460 V: 0.0–510.0
575 V: 0.0–733.1
Determined
by O02-04
E01-06 Base Frequency Motor Base Frequency 0.0–150.0 Hz 60.0
E01-07 Mid Frequency A Motor Middle output frequency 0.0–150.0 Hz Determined
by E01-03
E01-08 Mid Voltage A Motor Middle output frequency
Voltage
230 V: 0.0–255.0
460 V: 0.0–510.0
575 V: 0.0–733.1
Determined
by E01-03
E01-09 Min Frequency Minimum Frequency 0.0–150.0 Hz Determined
by E01-03
E01-10 Min Voltage Motor Minimum output frequency
Voltage
230 V: 0.0–255.0
460 V: 0.0–510.0
575 V: 0.0–733.1
Determined
by E01-03
E01-11 Mid Frequency B Midpoint Output Frequency B 0.0–150.0 Hz 0.0
E01-12 Mid Voltage B Midpoint Output
Voltage B
230 V: 0.0–255.0
460 V: 0.0–510.0
575 V: 0.0–733.1
0.0
E01-13 Base Voltage Motor Base Voltage 230 V: 0.0–255.0
460 V: 0.0–510.0
575 V: 0.0–733.1
0.0
* Initial value determined by X-Press Programming (Table 4-6, 4-7, or 4-8 on pages 4-12, 4-13, and 4-14).
