IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-71
Table 5-57: Voltage/Frequency (V/f) Pattern Options (230 V)
Table 5-58:Voltage/Frequency (V/f) Pattern Options (460 V)
E01-04 E01-05*
3
E01-06 E01-07 E01-08*
4
E01-09 E01-10*
4
E01-11 E01-12*
4
E01-13*
4
E01-03HzVACHzHzVACHzVACHzVACVAC
0* 60.0 230.0 60.0 3.0 15.0 1.3 8.1 0.0 0.0 0.0
1 60.0 230.0 60.0 3.0 16.1 1.3 9.2 0.0 0.0 0.0
2 60.0 230.0 60.0 3.0 17.3 1.3 10.4 0.0 0.0 0.0
3 60.0 230.0 60.0 3.0 18.4 1.3 11.5 0.0 0.0 0.0
4*
1
60.0 230.0 60.0 3.0 19.6 1.3 12.7 0.0 0.0 0.0
5 60.0 230.0 60.0 3.0 20.7 1.3 13.8 0.0 0.0 0.0
6 60.0 230.0 60.0 3.0 21.9 1.3 15.0 0.0 0.0 0.0
7 60.0 230.0 60.0 3.0 23.0 1.3 16.1 0.0 0.0 0.0
8 60.0 230.0 60.0 3.0 24.2 1.3 17.3 0.0 0.0 0.0
9*
2
50.0 200.0 50.0 25 13.0 1.1 7.0 0.0 0.0 0.0
A 50.0 200.0 50.0 25 15.0 1.1 9.0 0.0 0.0 0.0
B*
3
50.0 200.0 50.0 25 17.0 1.1 11.0 0.0 0.0 0.0
C 50.0 200.0 50.0 25 19.0 1.1 13.0 0.0 0.0 0.0
D 75.0 200.0 50.0 25 17.0 1.1 11.0 0.0 0.0 0.0
E 90.0 230.0 60.0 30 19.6 1.3 12.7 0.0 0.0 0.0
US (V/f) F
& FF
60.0 230.0 60.0 3.0 19.6 1.3 12.7 0.0 0.0 0.0
Euro (V/f) F
& FF
50.0 200.0 50.0 2.5 17.0 1.3 11.0 0 0 0
US (OLV) F
& FF
60.0 230.0 60.0 3.0 13.8 0.5 2.9 0 0 0
Euro (OLV)
F& FF
50.0 200.0 50.0 2.5 12.0 0.5 2.5 0 0 0
* Default for O02.09 = 1 and not Std Hoist
*1 Default for O02.09 = 1 and Std Hoist
*2 Default for O02.09 = 2 and not Std Hoist
*3 Default for O02.09 = 2 and Std Hoist
E01-04 E01-05*
3
E01-06 E01-07 E01-08*
4
E01-09 E01-10*
4
E01-11 E01-12*
4
E01-13*
4
E01-03HzVACHzHzVACHzVACHzVACVAC
0* 60.0 460.0 60.0 3.0 29.9 1.3 16.2 0.0 0.0 0.0
1 60.0 460.0 60.0 3.0 32.2 1.3 18.4 0.0 0.0 0.0
2 60.0 460.0 60.0 3.0 34.6 1.3 20.8 0.0 0.0 0.0
3 60.0 460.0 60.0 3.0 36.8 1.3 23.0 0.0 0.0 0.0
4*
1
60.0 460.0 60.0 3.0 39.1 1.3 25.4 0.0 0.0 0.0
5 60.0 460.0 60.0 3.0 41.4 1.3 27.6 0.0 0.0 0.0
6 60.0 460.0 60.0 3.0 43.8 1.3 30.0 0.0 0.0 0.0
7 60.0 460.0 60.0 3.0 46.0 1.3 32.2 0.0 0.0 0.0
8 60.0 460.0 60.0 3.0 48.4 1.3 34.6 0.0 0.0 0.0
9 50.0 400.0 50.0 2.5 26.1 1.1 14.1 0.0 0.0 0.0
A 50.0 400.0 50.0 2.5 30.1 1.1 18.1 0.0 0.0 0.0
B 50.0 400.0 50.0 2.5 34.1 1.1 22.1 0.0 0.0 0.0
C 50.0 400.0 50.0 2.5 38.1 1.1 26.1 0.0 0.0 0.0
* Default for O02.09 = 1 and not Std Hoist
*1 Default for O02.09 = 1 and Std Hoist
*2 Default for O02.09 = 2 and not Std Hoist
*3 Default for O02.09 = 2 and Std Hoist

Magnetek Impulse G+ series 4 Specifications

General

Output Frequency	0 - 400 Hz
Humidity	5% to 95% non-condensing
Dimensions	Varies by model
Weight	Varies by model
Enclosure	NEMA 1, NEMA 12, NEMA 4
Communication	Profibus
Output Current	Varies by model
Control Method	Closed Loop Vector Control
Display	LCD
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short Circuit
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
