IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-76
F01-12 PG2 Rotation Sel Changing this parameter has the
same effect as swapping A+ and
A- encoder wires.
0, 1 0 VG+
0 Fwd = C.C.W.
1Fwd = C.W.
F01-13 PG2 #Gear Teeth1 Sets the gear ratio between the
motor shaft and the encoder
(PG).
A gear ratio of 1 will be used if
F01-13 or F01-14 are set to 0.
0–1000 0 VG+
F01-14 PG2 #Gear Teeth2 Sets the gear ratio between the
motor shaft and the encoder
(PG).
A gear ratio of 1 will be used if
F01-13 or F01-14 are set to 0.
0–1000 0 VG+
F01-15 PG2 Output Ratio Sets the division ratio for the
pulse monitor used of the PG
option card installed to port CN5-
B.
1–132 1 VG+
F01-16 PGO-2-H Delay time for PGO-2-H
detection. A setting of zero
disables PGO-2-H detection.
Channel 2 is associated with slot
CN5-B.
0–100 ms 15 VG+
F01-21 PG Fdbk Loss Sel Stopping method when PGO-1-S
or PGO-2-S faults are detected.
Traverse: 0–3
NLB: 1
1VG+
0 Decel to Stop Decelerate to stop using the
deceleration time in B05-02.
1 Coast to Stop
2Fast Stop Decelerate to stop using the
deceleration time in B05-08.
3 Alarm Only
F01-22 PGO-1-S Det Time PGO-1-S (CH1) disconnection
detection time. A setting of zero
disables PGO-1-S detection.
0.0–10.0 sec 2.0 VG+
F01-23 PG Overspeed Sel Sets the stopping method when
an overspeed (OS) fault occurs.
Traverse: 0–3
NLB: 1
1VG+
0 Decel to Stop Decelerate to stop using the
deceleration time in B05-02.
1 Coast to Stop
2Fast Stop Decelerate to stop using the
deceleration time in B05-08.
3 Alarm Only
F01-24 PG Overspd Level Sets the overspeed detection
level as a percentage of the
maximum output frequency.
0–120% 105 VG+
F01-25 PG Overspd Time Sets the time in seconds for an
overspeed situation to trigger a
fault (oS).
0.0–2.0 sec 0.0 VG+
Parameter Display Function Range Default Model
