IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-91
C Anti-Shock ON ON/CLOSED: When Anti-Shock is enabled and a torque spike is detected.
OFF/OPEN: When torque is stable and a spike is not detected.
D DB Overheat ON/CLOSED: When the drive displays an “RH” or “RR” fault
OFF/OPEN: When the drive is not in an “RH” or “RR” fault condition
EFault ON/CLOSED: When the drive is in a fault condition (excluding CPF00 and CPF01)
OFF/OPEN: When the drive is not in a fault condition
FNot Used* No Function
10 Minor Fault ON/CLOSED: When the drive is in a minor fault condition
OFF/OPEN: When the drive is not in a minor fault condition
11 Reset Cmd
Active
ON/CLOSED: When there is a reset command present using the terminals, serial
communications, or communication option card
OFF/OPEN: When a reset command is not present
12 Timer Output ON/CLOSED: When H01-xx = 43 is active for longer than C12-03 time
OFF/OPEN: When H01-xx = 43 is not active
13 Fref/Fout
Agree2
ON/CLOSED: When the output frequency (U01-02) is within the frequency reference
(U01-01) ±L04-04
OFF/OPEN: When the output frequency (U01-02) is not within the frequency reference
(U01-01) ±L04-04
14 Fref/Set Agree 2 ON/CLOSED: When the output frequency (U01-02) is within L04-03 ±L04-04
OFF/OPEN: When the output frequency (U01-02) is not within L04-03 ±L04-04
18 Trq Det 2 N.O. ON/CLOSED: When the output current/torque exceeds the value set in parameter L06-
05 for longer than the time set in parameter L06-06
OFF/OPEN: When the output current/torque does not exceed the value set in
parameter L06-05 for longer than the time set in parameter L06-06
1A Forward Dir ON/CLOSED: During Forward/Up operation
OFF/OPEN: When running in Reverse/Down direction or baseblock
1B Reverse Dir ON/CLOSED: During Reverse/Down operation
OFF/OPEN: When running in Forward/Up direction or baseblock
1C Swift/Ultra-Lift
Mode
ON/CLOSED: When the drive is operating in Swift-Lift/Ultra-Lift mode
OFF/OPEN: When the drive is not operating in Swift-Lift/Ultra-Lift mode
1D Brk Trans Fault ON/CLOSED: When the drive detects a brake transistor failure
OFF/OPEN: Normal operation
1E LC Operating ON/CLOSED: When the drive is testing the current load before posting a LC Fault
OFF/OPEN: Normal operation
1F Regenerating ON/CLOSED: When the drive is in a regenerative mode
OFF/OPEN: Normal operation
20 Auto-Rst
Attempt
ON/CLOSED: When Auto-reset is enabled
OFF/OPEN: Normal operation
21 Overload (OL1) ON/CLOSED: When the drive exceeds 90% of the motor overload detection level (oL1)
OFF/OPEN: Normal operation
22 OH Pre-Alarm ON/CLOSED: When the drive heatsink temperature ≥ L08-02
OFF/OPEN: Normal operation
23 Torque Limit ON/CLOSED: When the torque (U01-09) is ≥ C07-01–C07-04.
OFF/OPEN: Normal operation
24 Speed Limit ON/CLOSED: When:
1. the frequency reference has reached the upper limit set in B02-01 (D02-01).
2. the frequency reference has fallen below B02-02 (D02-02) or B02-03 (D02-03).
3. parameter B03-05 (B01-05) = 1, 2, or 3, and the frequency reference is < E01-09.
OFF/OPEN: Normal operation
Display Function
* This output does not have an inverse output
** Contact will open when power is disconnected
