25 During Load Flt ON/CLOSED: When drive is in Load Float
OFF/OPEN: When drive is not in Load Float
26 Run Cmd is
Input
ON/CLOSED: When either a Forward or Reverse command is active on H01-xx
OFF/OPEN: When neither a Forward or Reverse command is active on H01-xx
27 Load Check Det ON/CLOSED: When the drive has detected a Load Check fault
OFF/OPEN: Normal operation
28 Slack Cable Det ON/CLOSED: When the drive has detected a Slack Cable
OFF/OPEN: Normal operation
29 Upper Limit ON/CLOSED: When a UL1, UL2, or UL3 is detected
OFF/OPEN: Normal operation
2A During RUN 2 ON/CLOSED: When a run command is active and the drive is outputting voltage.
2B Upper Limit 1 ON/CLOSED: When UL1 is detected
OFF/OPEN: Normal operation
2C Upper Limit 2 ON/CLOSED: When UL2 is detected
OFF/OPEN: Normal operation
2D Lower Limit 1 ON/CLOSED: When LL1 is detected
OFF/OPEN: Normal operation
2E Lower Limit 2 ON/CLOSED: When LL2 is detected
OFF/OPEN: Normal operation
30 Lower Limit ON/CLOSED: When LL1 or LL2 is detected
OFF/OPEN: Normal operation
31 Up/Low Limit ON/CLOSED: UL1, UL2, UL3, LL1, or LL2 is detected
OFF/OPEN: Normal operation
32 Snap Shaft ON/CLOSED: When the drive has detected a Snap Shaft
OFF/OPEN: Normal operation
34 Index Complete ON/CLOSED: When the Index move is complete
OFF/OPEN: Normal operation or Index move is not complete
35 Ready for F-Ref ON/CLOSED: When C08-04 timer has expired or the Brake Answerback is detected
H01-xx = 58 is true
OFF/OPEN: Normal operation or drive detected a BE1, BE2, BE4 alarm or is stopped.
36 Fan Alrm Det ON/CLOSED: When the drive detects that the internal cooling fan has failed
OFF/OPEN: Normal operation
37 Maintenance ON/CLOSED: When the Maintenance Timer U01-52 ≥ C12-05
OFF/OPEN: Normal operation or the Maintenance Timer U01-52 < C12-05
38 Spd Lim @ T
Cont
ON/CLOSED: When Speed Limit has been reached while using Torque Control
OFF/OPEN: When the Speed Limit has not been reached when using Torque Control
39 Drive Enable ON/CLOSED: When Drive is Enabled
OFF/OPEN: When Drive Enable (H01-xx =65) is not active
3B Watt-hour Pulse ON/CLOSED: When the Watt-hour time is reached (based on setting of H02-06), the
contact will close for 200 ms
OFF/OPEN: When the Watt-hour time has not been reached
3D Fault or Alarm ON/CLOSED: When either a Fault or Alarm condition is detected
OFF/OPEN: Normal operation
3E Overspeed ON/CLOSED: When an overspeed condition is detected
OFF/OPEN: Normal operation
3F Klixon ON/CLOSED: When a Klixon alarm is detected (H01-xx = 56 or 57 is active)
OFF/OPEN: Normal operation
Display Function
* This output does not have an inverse output
** Contact will open when power is disconnected
