IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
6-26
Table 6-6: Fault Codes for Option Cards
Error Card
Fault or Indicator
Name/Description Cause Possible Solution
oFA00
A1-A3
AO-A3
DI-A3
DO-A3
S4I
S4IO
Option Card Connection
Error at Option Port CN5-
A.
• The option card
installed into port CN5-
A is incompatible with
the drive.
• A PG option card is
connected to option
port CN5-A.
• Check if the drive
supports the option
card to be installed.
Contact Magnetek for
assistance.
• PG option cards are
supported by option
ports CN5-B and CN5-
C only. Connect the PG
option card to the
correct option port.
oFA01
A1-A3
AO-A3
DI-A3
DO-A3
S4I
S4IO
Option Fault (CN5-A).
Option is not properly
connected.
• Option at drive port
CN5-A was changed
during run.
• Turn the power off and
check the connectors
between the drive and
the option.
oFB01
A1-A3
AO-A3
DI-A3
DO-A3
S4I
S4IO
Option Fault (CN5-B).
Option is not properly
connected.
• Option at drive port
CN5-B was changed
during run.
• Turn the power off and
check the connectors
between the drive and
the option.
oFB02
A1-A3
AO-A3
DI-A3
DO-A3
S4I
S4IO
Option Fault (CN5-B).
Two of the same option
cards are connected
simultaneously.
• AI-A3: AI-A3 option
connected to CN5-B
port while another input
option was connected
to CN5-A port.
• DI-A3: DI-A3 option
connected to CN5-B
port while another input
option was connected
to CN5-A port.
• AO-A3/DO-A3:
Duplicate type of
option card is
connected to drive
ports CN5-A, CN5-B,
and CN5-C.
• AI-A3: Only one of the
options, AI-A3, DI-A3,
or SI-xx can be
connected to the drive
at the same time.
• DI-A3: Only one of the
options, AI-A3, DI-A3,
or SI-xx can be
connected to the drive
at the same time.
• AO-A3/DO-A3: Use
only compatible
options.
oFC00
A1-A3
AO-A3
DI-A3
DO-A3
S4I
S4IO
Option connection error
at drive port CN5-C.
• The option card
installed into port CN5-
C is incompatible with
the drive
• A communication
option card has been
installed in option port
CN5-C
• Confirm that the drive
supports the option
card to be installed.
Contact Magnetek for
assistance.
• Communication option
cards are only
supported by option
port CN5-A. It is not
possible to install more
than one
communication option.
