IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
4-12
Parameters Changed by X-Press Programming
Table 4-6: Traverse (A01-03= 0) for G+ and VG+S4 Models
Parameter Description
A01-04 =
012 3 4567 8
2-Speed
Multi-
Step
3-Speed
Multi-
Step
5-Speed
Multi-
Step
2-Step
Infinitely
Variable
3-Step
Infinitely
Variable
Uni-
Polar
Analog
Bi-Polar
Analog
Indus-
trial
Coms
RS485/
RDSI
Coms
B01-01 Speed 1 20.00 15.00 6.00 6.00 6.00 0.00 0.00 15.00 0.00
B01-02 Speed 2 60.00 30.00 15.00 0.00 0.00 0.00 0.00 30.00 0.00
B01-03 Speed 3 0.00 60.00 30.00 0.00 0.00 0.00 0.00 60.00 0.00
B01-04 Speed 4 0.00 0.00 45.00 0.00 0.00 0.00 0.00 0.00 0.00
B01-05 Speed 5 0.00 0.00 60.00 0.00 0.00 0.00 0.00 0.00 0.00
B01-06–16 Speed 6–16 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
B01-17 Jog Ref 6.00 6.00 6.00 6.00 6.00 6.00 6.00 6.00 6.00
B01-18 Ref Priority 0 0 0 0 0 1 1 0 1
B02-03 Ref. Lower Limit 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
B03-01 Freq. Ref. Select 1 1 1 1 1 1 1 3 2
B03-02 Run Cmd Select 1 1 1 1 1 1 1 3 2
B03-03 Stopping Method 0 0 0 0 0 0 0 0 0
B05-01 Accel Time 1 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0
B05-02 Decel Time 1 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0
C01-01 Quick Stop 0 0 0 0 0 0 0 0 0
C03-07 Action @ LL1/UL2 2 2 2 2 2 2 2 2 2
C08-10 Load Float Time 0 0 0 0 0 0 0 0 0
C13-12 Index Brake Ctrl 0 0 0 0 0 0 0 0 0
D09-01 S-Curve Accel at Start 1.50 1.50 1.50 1.50 1.50 1.50 1.50 1.50 1.50
D09-02 S-Curve Accel at End 1.50 1.50 1.50 1.50 1.50 1.50 1.50 1.50 1.50
D09-03 S-Curve Decel at Start 1.50 1.50 1.50 1.50 1.50 1.50 1.50 1.50 1.50
E01-03 V/f Selection 000000 00 00000000 00
H01-01 Terminal S1 Select 80 80 80 80 80 80 80 80 0F
H01-02 Terminal S2 Select 81 81 81 81 81 81 81 81 0F
H01-03 Terminal S3 Select 00 00 00 05 04 0F 0F 0F 0F
H01-04 Terminal S4 Select 0F 01 01 0F 05 0F 0F 0F 0F
H01-05 Terminal S5 Select 0F 0F 02 0F 0F 0F 0F 0F 0F
H01-06 Terminal S6 Select 0F 0F 03 0F 0F 0F 0F 0F 0F
H01-07 Terminal S7 Select 0F 0F 0F 0F 0F 0F 0F 0F 0F
H01-08 Terminal S8 Select 0F 0F 0F 0F 0F 0F 0F 0F 0F
H02-01 Terminal M0/M1 Select 000 000 000 000 000 000 000 000 000
H02-02 Terminal M2/M3 Select 00F 00F 00F 00F 00F 00F 00F 00F 00F
H02-03 Terminal M5/M6 Select 00F 00F 00F 00F 00F 00F 00F 00F 00F
H03-01 Terminal A1 Signal Level 0 0 0 0 0 0 1 0 0
H03-02 Terminal A1 Select 0 0 0 0 0 0 0 0 0
H03-06 Terminal A3 Select 1F 1F 1F 1F 1F 1F 1F 1F 1F
H03-10 Terminal A2 Select 1F 1F 1F 1F 1F 1F 1F 1F 1F
