Magnetek Impulse G+ series 4 User Manual

IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
5-11
B03-16 Run Source 2 Determines what the drive will use
for Run Reference. Enabled by
MFDI programmed to IF.
0–3 0
0Operator Digital Operator
1 Terminals Terminals
• S4-IF Interface Card
• S4-I AC Digital Input Option
• S4-IO Digital Input/Output Option
• DI-A3 Digital Input Option (not used for
B03-02)
2 Serial Com Serial communication
• RS485/422 Serial Communications
(R+, R-, S+, S-)
3Option PCB Industrial Communication Option
card (Port CN5-A)
• EtherNet/IP
• Modbus TCP/IP
• PROFINET
• PROFIBUS-DP
B03-21 PG Start Sel Allows the drive to start when the
Frequency Reference is between
D01-01 and E01-09.
0, 1 0
0 RejectRunCmd
1 AcceptRunCmd
Parameter Display Function Range Default
