MAN B&W 5.06
Page  of 8
MAN Diesel
MAN B&W S50MC-C8
198 60 79-4.0
Fig. 5.06.01a: Engine outline, S50MC-C8 with turbocharger on aft end
502 40 22-1.3.0a
Engine and Gallery Outline




,)æçæ,))æçæ,)))






  
A G
Cylinder no. g L I L II L III
5 3,400 5,924 6,47 6,424
6 4,250 6,774 6,997 7,274
7 5,00 7,624 7,847 8,24
8 5,950 8,474 8,697 8,974
9 Data for 9 cylinders is available on request.
Types of
fore end
Typical for
cylinder no.
Space demand valid for
I
7-8 Basic design
I I
5-6 2nd order moment compensator
I I I
5-6
2nd order moment compensator
and tuning wheel
T/C Type a b c
MAN
Diesel
TCA66* ,950 6,375 250
TCA77* 2,20 6,490 220
ABB
TPL73B-CL* ,826 5,85 350
TPL77B* 2,086 6,225 282
TPL80B* 2,00 6,200 259
MHI
MET53MA Available on request
MET60MA* 2,00 6,253 376
MET66MA
Available on request
MET83MA
* Dimension given are only preliminary.
