Man B&W S50MC-C8-TII - Sequence Diagram for Engines with Fixed Pitch Propeller

MAN B&W 16.01
Page 11 of 11
MAN Diesel
MAN B&W S50MC/MC-C, S46MC/C, S42MC, S40MC-C,
S/L35MC, S35MC-C, S26MC
198 66 39-1.2
Sequence diagram for engines with Fixed Pitch Propeller
178 58 18-8.0
Fig. 16.01.08a: Sequence diagram for fixed pitch propeller, MC/MC-C types 50-26
