MAN Diesel
MAN B&W S50MC-C7/8, S50MEC7/8,
S50ME-B8
198 46 666.3
Large spare parts, dimensions and masses
Pos Sec. Description
Mass Dimensions (mm)
(kg) A B C D E
 Cylinder liner, incl. cooling jacket ,88 ø690 2,85 ø590
2 Exhaust valve 449 ,30 665 494
3 Piston complete, with piston rod 930 ø500 349 ø95 2,855 320
4 Cylinder cover, incl. valves ,96 ø92 420
5 Rotor for turbocharger, TCA 66-20/2 220 ø630 ,70
5 Rotor for turbocharger, TCA 77-20/2 360 ø750 ,360
5 Rotor for turbocharger, TPL73-B2 5 ø507 963
5 Rotor for turbocharger, TPL77-B2 90 ø602 ,36
5 Rotor for turbocharger, TPL80-B2 300 ø699 ,39
5 Rotor for turbocharger, MET53MA 90 ø586 ,035
5 Rotor for turbocharger, MET60MA 240 ø652 ,88
5 Rotor for turbocharger, MET66MA 330 ø730 ,27
5 Rotor for turbocharger, MET7MA 400 ø790 ,38
Fig. 19.09.01: Large spare parts, dimensions and masses
178 43 43-6.1
!
"
%
!
"
#
!
"
#
!
#
$
!
"
"
 



