MAN B&W 14.05
Page 2 of 2
MAN Diesel
MAN B&W S50MC-C, S50ME-C, S50ME-B8 198 54 02-4.2
The letters refer to list of ‘Counterflanges‘
Fig. 14.05.03: Air cooler cleaning system with Air Cooler Cleaning Unit, option: 4 55 665
No. of cylinders
5-8 9
Chemical tank capacity 0.3 m
3
0.6 m
3
Circulation pump capacity at 3 bar 1 m
3
/h 2 m
3
/h
Air cooler
Sludge pump suction
Freshwater
(from hydrophor)
AM
Heating coil
To fit the chemical
maker’s requirement
DN=25 mm
AK
Recirculation
AL
DN=50 mm
DN=50 mm
Circulation
pump
Filter
1 mm mesh size
Drain from air cooler
cleaning & water mist
catcher in air cooler
Chemical
cleaning tank
PI
TI
079 61 05-4.1.1c
Air Cooler Cleaning Unit
AL
Clean bilge tank /
bilge holding tank
Drain water
collecting tank
Overboard
High level alarm
Start pump
Stop pump
Low level alarm
Oil in water
monitor
(15ppm oil)
Hull
To oily water
separator
Fig. 14.05.02: Suggested automatic disposal of drain water, if required by owner (not a demand from MAN Diesel)
079 21 94-1.0.0d
Auto Pump Overboard System
