MAN B&W 14.04
Page of
MAN Diesel
MAN B&W S50MC-C8, S50ME-C8, S50ME-B8 198 62 29-3.1
Table 14.04.01: Electric motor for auxiliary blower, engine with turbocharger located on aft end or exhaust side
The installed power of the electric motors are based on a voltage supply of 3x440V at 60Hz.
The electric motors are delivered with and tted onto the engine.
Electric Motor for Auxiliary Blower
Number of
cylinders
Number of auxiliary
blowers
Required power/blower
kW
Installed power/blower
kW
5
2
3
35
6 37 43
7 43 49
8 49 49
9 54 54
The number of auxiliary blowers in a propulsion
plant may vary depending on the actual amount of
turbochargers as well as space requirements.
For typical engine congurations, the required
power of the auxiliary blowers as well as the in-
stalled size of the electric motors are listed in Ta-
ble 4.04.0.
