MAN B&W 19.04
Page 1 of 4
MAN Diesel
MAN B&W S50MC-C 198 65 75-4.0
Dispatch pattern, list of masses and dimensions
Pattern Section
5 cylinder 6 cylinder 7 cylinder
Mass Length Mass Length Mass Length Height Width
In t in m In t in m in t in m in m in m
A1+B1 Engine complete
185.4 8.4 211.1 9.3 237.0 10.1 9.1 5.5
A2+B2
Top section 67.7 8.3 78.2 9.2 88.8 10.0 6.7 5.5
Bottom section 111.2 8.4 126.1 9.3 141.1 10.1 5.6 4.6
Remaining parts 6.5 6.8 7.1
A3+B3
Top section 67.7 8.3 78.2 9.2 88.8 10.0 6.7 5.5
Frame box section 46.4 8.4 52.2 9.3 55.0 10.1 3.4 4.6
Bedplate/Crankshaft 64.7 5.9 73.9 6.7 86.1 7.6 3.0 3.2
Remaining parts 6.5 6.8 7.1
A4+B4
Top section 45.3 6.4 54.3 7.3 63.3 8.1 4.0 3.6
Exhaust receiver 4.8 4.6 5.6 5.4 6.3 6.3 2.6 1.8
Scavenge air receiver 5.5 5.6 6.2 6.4 7.0 7.3 2.1 2.2
Turbocharger, each 5.1 5.1 5.1
Air cooler - insert 1.4 1.4 1.4
Air cooler, box 4.2 2.1 4.2 2.1 4.2 2.1 2.6 3.9
Frame box section 47.4 8.4 53.2 9.3 56.0 10.1 3.4 4.2
Crankshaft 37.0 5.9 42.0 6.8 49.9 7.6 3.0 3.0
Bedplate 27.5 6.3 31.7 7.1 36.0 8.0 2.5 3.4
Remaining parts 7.1 7.5 7.8
