MAN B&W 19.04
Page 2 of 4
MAN Diesel
MAN B&W S50MC-C 198 65 75-4.0
Pattern Section
8 cylinder 9 cylinder
Mass Length
Available on request
Height Width
in t in m in m in m
A1+B1 Engine complete
270.9 11.0 9.1 5.5
A2+B2
Top section 105.2 10.9 6.7 5.5
Bottom section 158.3 11.0 5.6 4.6
Remaining parts 7.4
A3+B3
Top section 105.2 10.9 6.7 5.5
Frame box section 61.0 11.0 3.4 4.6
Bedplate/Crankshaft 97.2 8.4 3.0 3.2
Remaining parts 7.4
A4+B4
Top section 72.3 9.0 4.0 3.6
Exhaust receiver 7.1 7.1 2.6 1.8
Scavenge air receiver 7.7 8.1 2.1 2.2
Turbocharger, each 9.8
Air cooler - insert 2.5
Air cooler, box 4.2 2.1 2.6 3.9
Frame box section 62.0 11.0 3.4 4.2
Crankshaft 56.8 8.5 3.0 3.0
Bedplate 40.2 8.8 2.5 3.4
Remaining parts 8.3
The weights stated are for standard engines with semibuilt crankshaft with forged throws, crosshead guides inte-
grated in the frame box and MAN Diesel turbocharger. All masses and dimensions in the dispatch pattern are there-
fore approximate and do not include packing and lifting tools. The masses of tuning wheel, turbocharger specified in
dispatch pattern outline can vary, and should be checked. Moment compensator and tuning wheel are not included in
dispath pattern outline.
Table 19.04.01: Dispatch pattern, list of masses and dimensions for engines with turbocharger aft
