Man B&W S50MC-C8-TII

MAN B&W 19.04
Page 3 of 4
MAN Diesel
MAN B&W S50MC-C 198 65 75-4.0
Pattern Section
5 cylinder 6 cylinder 7 cylinder
Mass Length Height Width Mass Length Height Width
in t in m in m in m in t in m in m in m
A1+B1 Engine complete
186.0 7.4 212.4 8.3 238.4 9.1 9.1 6.9
A2+B2
Top section 67.5 7.2 78.5 8.1 89.6 8.9 4.4 6.9
Bottom section 111.5 7.4 126.7 8.3 141.3 9.1 5.3 4.6
Remaining parts 7.0 7.3 7.6
A3+B3
Top section 67.5 7.2 78.5 8.1 89.6 8.9 4.4 6.9
Frame box section 46.6 7.4 52.5 8.3 55.3 9.1 3.3 5.0
Bedplate/Crankshaft 64.9 5.9 74.2 6.7 86.0 7.6 3.0 3.2
Remaining parts 7.0 7.3 7.6
A4+B4
Top section 45.4 7.2 54.4 8.1 63.5 8.9 4.0 3.6
Exhaust receiver 3.8 5.1 4.6 5.9 5.3 6.8 2.6 1.8
Scavenge air receiver 10.7 5.1 12.0 5.9 13.3 6.8 3.1 3.5
Turbocharger, each 5.1 5.1 5.1
Air cooler - each 2.0 2.0 2.0
Frame box section 47.0 7.4 52.9 8.3 55.7 9.1 3.3 4.8
Crankshaft 37.2 5.9 42.3 6.8 49.8 7.6 3.0 3.0
Bedplate 27.2 6.3 31.5 7.1 35.7 8.0 2.5 3.4
Remaining parts 7.5 7.7 8.0
