Table 19.04.02: Dispatch pattern, list of masses and dimensions for engines with turbocharger on exhaust side
Pattern Section
8 cylinder 9 cylinder
Mass Length
Available on request
Height Width
in t in m in m in m
A1+B1 Engine complete
272.5 10.0 9.1 6.9
A2+B2
Top section 106.3 9.8 4.4 6.9
Bottom section 157.7 10.0 5.3 4.6
Remaining parts 8.5
A3+B3
Top section 106.3 9.8 4.4 6.9
Frame box section 61.5 10.0 3.3 5.0
Bedplate/crankshaft 96.2 8.4 3.0 3.2
Remaining parts 8.5
A4+B4
Top section 72.8 9.8 4.0 3.6
Exhaust receiver 6.4 7.6 2.6 1.8
Scavenge air receiver 15.7 7.6 3.1 3.5
Turbocharger - each 3.7
Air cooler - each 1.8
Frame box section 61.9 10.0 3.3 4.8
Crankshaft 55.8 8.5 3.0 3.0
Bedplate 40.0 8.8 2.5 3.4
Remaining parts 9.0
The weights stated are for standard engines with semibuilt crankshaft with forged throws, crosshead guides inte-
grated in the frame box and MAN Diesel turbocharger. All masses and dimensions in the dispatch pattern are there-
fore approximate and do not include packing and lifting tools. The masses of tuning wheel, turbocharger specified in
dispatch pattern outline can vary, and should be checked. Moment compensator and tuning wheel are not included in
dispath pattern outline.
