MAN B&W 4.03
Page 2 of 6
MAN Diesel
198 43 156.2MAN B&W K98MC/MC-C/ME/ME-C, S90MC-C/ME-C,
K90MC-C/ME/ME-C, S80MC/MC-C/ME-C, K80MC-C/ME-C,
S70MC/MCC/ME-C/ME-GI, L70MCC/ME-C, S65ME-C/ME-GI,
S60MC/MC-C/ME-C/ME-GI/ME-B, L60MC-C/ME-C,
S50MC/MC-C/ME-C/ME-B
Pos.
1 Special face on bedplate and frame box
2 Ribs and brackets for supporting the face and machined blocks for alignment of gear or stator housing
3 Machined washers placed on frame box part of face to ensure that it is flush with the face on the bedplate
4 Rubber gasket placed on frame box part of face
5 Shim placed on frame box part of face to ensure that it is flush with the face of the bedplate
6 Distance tubes and long bolts
7 Threaded hole size, number and size of spring pins and bolts to be made in agreement with PTO maker
8 Flange of crankshaft, normally the standard execution can be used
9 Studs and nuts for crankshaft flange
10 Free flange end at lubricating oil inlet pipe (incl. blank flange)
11 Oil outlet flange welded to bedplate (incl. blank flange)
12 Face for brackets
13 Brackets
14 Studs for mounting the brackets
15 Studs, nuts and shims for mounting of RCF/generator unit on the brackets
16 Shims, studs and nuts for connection between crankshaft gear and RCF/generator unit
17 Engine cover with connecting bolts to bedplate/frame box to be used for shop test without PTO
18 Intermediate shaft between crankshaft and PTO
19 Oil sealing for intermediate shaft
20 Engine cover with hole for intermediate shaft and connecting bolts to bedplate/frame box
21 Plug box for electronic measuring instrument for checking condition of axial vibration damper
22 Tacho encoder for ME control system or Alpha lubrication system on MC engine
23 Tacho trigger ring for ME control system or Alpha lubrication system on MC engine
Pos. no: 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23
BWIII/RCF A A A A B A B A A A A A B B A A A
BWIII/CFE A A A A B A B A A A A A B B A A A
BWII/RCF A A A A A A A
BWII/CFE A A A A A A A
BWI/RCF A A A A B A B A A A
BWI/CFE A A A A B A B A A A A A
DMG/CFE A A A B C A B A A A
A: Preparations to be carried out by engine builder
B: Parts supplied by PTOmaker
C: See text of pos. no.
178 89 342.0
Fig. 4.03.01b: Engine preparations for PTO
