MAINTENANCE CD3340B/YB4411
5-4
Published 04/07/2015 Control # 569-00
Inspect Reeving, Clamps and
Connections
X5-13
Inspect The Lifting Hook
X5-13
Inspect Safety Devices
X5-13
Check Controls Operation
X5-13
Check Engine Crankcase Oil Level
X5-14
Check Transmission Oil Level
X5-14
Check Engine Coolant Level
X5-14
Check Fuel Level
X5-13
Check Tire Pressure
X5-16
Drain Water From Engine
Fuel Filter/Water Separator
X5-15
Check Air Cleaner Restriction
Indicator
X5-16
Check Hydraulic Oil Level
X5-15
Inspect Wire Rope and Sheaves
X5-17
Apply Grease to All Lubrication
Fittings
X5-17
Lubricate the Boom Slides
X5-18
Lubricate the Boom Chains
X5-18
Clean Air Cleaner Dust Cup
X5-17
Inspect The Engine Fan Belts
X5-19
Check Wheel Nut Torque
X5-19
Lubricate the Swing Gear and Pinion
X5-23
Lubricate the Wire Rope
X5-22
Inspect The Boom Chains
X5-20
Inspect All Hydraulic Hose
X5-21
Replace Engine Crankcase Oil*
X5-23
Replace Engine Oil Filter*
X5-23
Clean Radiator Fins and Core
X5-23
Clean Battery and Connections
X5-22
Torque Critical Bolts
X5-23
Check Axle Wheel Hub Lubricant
Level (2)
X5-28
Check Axle Housing Lubricant Level
X5-28
Check Boom Hoist Gearbox & Brake
Lubricant Level
X5-28
Lubricate the Outrigger Slides
X5-27
SERVICE/CHECK
INTERVAL
See Page
Daily
Before
Operation
50
Hours
100
Hours
250
Hours
500
Hours
1000
Hours
2000
Hours
Reference Only
