MAINTENANCE CD3340B/YB4411
5-8
Published 04/07/2015 Control # 569-00
Notes: 1. All pintle hooks, etc. shall be oiled or greased as required.
Rear Steer Axle
7 Hub Bearings EP-MPG
8 Kingpin Bearings EP-MPG
9 Steer Linkage Bearing EP-MPG
10 Steering Cylinder EP-MPG
Engine & Trans.
11 Engine Crankcase 5.8-7.4 Qts (5.5-7.0 L) EO-15W-40 See Note 4
12 Engine Coolant 3.7 Gal (13.9 Liters) AFC See Notes 2 & 10
13 Transmission 4.5 Gal (17.0 Liters) HTF
Turntable
14 T/T Gear Box EP-MPG
15 T/T Gear & Pinion EP-OGL
16 T/T Bearing EP-MPG
Cylinders
17 O/R Cylinder ASC See Note 6
18 Lift Cylinder EP-MPG See Note 6
Boom
19 Boom Nose Sheaves EP-MPG
20 Jib Boom Sheave EP-MPG
21 Boom Sections EP-MPG See Note 9
22 Tele Cylinder Wear Pads EP-MPG
23 Boom Extension Sheave EP-MPG
24 Boom Ret Sheave EP-MPG
25 Hook Block Swivel Bearing EP-MPG
26 Boom Pivot Shaft EP-MPG
27 Hook Block Sheaves EP-MPG
Outriggers
28 Slide Box EP-MPG See Note 7
29 Jack Tube EP-MPG See Note 8
Hoist
30 Hoist Gearbox 1.0 Qts (0.95 Liters) EPGL-5
31 Hoist Brake 0.25 Qts (0.24 Liters) Transynd
32 Cable Follower EP-MPG
Misc.
33 Driveline Joints EP-MPG
34 Fuel Tank 17.0 Gal (64.4 Liters)
35 Hydraulic, Oil Tank 34.5 Gal (130.6 Liters) HYDO See Notes 4 & 5
No Location Name Capacity Symbol Instruction
Reference Only
