Manitowoc Grove CD3340B - Page 318

STRUCTURAL CD3340B/YB4411
11-26
Published 04/07/2015 Control # 569-00
AA0478
Item Description
1. Brake Housing
2. Capscrew (8)
3. Bushing
4. Seal
5. Spacer
6. Friction Disc (7)
7. Stator Plate (8)
8. Seal (2)
10. Piston
11. O-ring
12. Brake Cover
13. Bushing and Breather Kit
14. Capscrew (4)
15. Plug
16. Brake Spring (12)
17. Snap Ring (2)
18. Snap Ring (2)
19. Brake Driver
20. Race (2)
21. Bushing (2)
22. Clutch
23. Input Shaft
Item Description
FIGURE 11-46
FIGURE 11-47
P0200
FIGURE 11-48
P0201
Reference Only
