BOOM TMS700E SERVICE MANUAL
4-26 Published 01-29-2015, Control # 512-01
DETAIL A
DETAIL B
14
16
15
15
18
19
Item Description
14 Swingaway Base
15 Adjusting Bolt
16 Upper Hanger
17 Main Hanger
18 Lower Support
19 Lock Hitch Pin
Item Description
20 Swingaway Stinger
21 Adjusting Bolts
22 Adjusting Bolts
23 Front Mount
24 Hanger
20
21
21
22
23
24
FIGURE 4-5 continued
17
Reference Only
