Manitowoc Grove TMS700E User Manual

Grove Published 01-29-2015, Control # 512-01 4-27
TMS700E SERVICE MANUAL BOOM
4
DETAIL C
DETAIL D
Item Description
25 Swingaway Base
26 Swingaway Stinger
27 Shock Wear Pad and Shim
28 Ramp Wear Pad and Shim
27
26
30
25
28
32
38
34
39
31
32
33
36
37
29
35
FIGURE 4-5 continued
Item Description
29 Swingaway Base
30 Swingaway Stinger
31 Stinger Attach Pin and Hitch Pin
32 Adjusting Bolts
33 Pin Stowage Lug
34 Upper Support
35 Lower Mount
36 Wear pad
37 Pin Mount
38 Upper Hanger
39 Lower Hanger
Reference Only
