OPERATING CONTROLS AND PROCEDURES MLC165-1 OPERATOR MANUAL
3-56
Published 08-06-19, Control # 237-09_v1
SYMBOLS USED ON CONTROL CONSOLES
The following symbols are used on the control consoles to identify the operating controls and their operation.
Table 3-14. Symbol Identification
Air Conditioning Cylinder, Self-Assembly
Alert Symbol, Safety Decrease/Increase
Counterweight, All Drum
Counterweight, Left Drum, Free Fall
Counterweight, Right Drum, Lower or Raise
Cylinder, Extend and Retract Drum Number (position varies)
Cylinders, Mast Arms Drum 3/4 High Speed
