Manitowoc Published 08-06-19, Control # 237-09_v2 4-83
MLC165-1 OPERATOR MANUAL SETUP AND INSTALLATION
Install Crane from Trailer
See Figure 4-61.
1. Attach owner furnished lifting slings (2) from the assist
crane to shackles (3) at the lifting holes (4) in the rotating
bed of the MLC165-1.
Refer to the Lifting Assembly 81023872 at the end of this
section for sling and pick point specifications and for the
total weight to be lifted.
It is crane owner’s responsibility to properly size the
assist crane, the lifting slings, and the shackles for
the weight to be lifted.
2. Lift the MLC165-1 onto the trailer.
3. Secure the MLC165-1 to the trailer. See Shipping Crane
Components on page 4-53.
4. Disconnect the lifting slings and shackles.
5. The crane is ready for transport.
DANGER
Tipping Hazard!
Swing is prohibited while crane is on blocking.
