OPERATING CONTROLS AND PROCEDURES MLC165-1 OPERATOR MANUAL
3-14
Published 08-06-19, Control # 237-09_v1
Right Console
Table 3-5. Right Console
Item Name Description
1 Horn Switch
Press and hold the front of this switch to sound the horn.
Release the switch to silence the horn.
Before starting the engine, swinging, or traveling, sound the horn to
alert nearby personnel.
2 Travel Speed Selector
Press to operate the travel motors in high speed. High speed
operation provides maximum available travel speed for traveling long
distances.
Press to operate the travel motors in low speed. Low speed
operation provides smooth starts and stops and allows more precise control of
the travel motors than high speed.
M100234, M100210
Operator Cab
Right SideLeft Side
Front
8
7
1
2
6
4
3
5
9
To Next Page
