Manitowoc Published 08-06-19, Control # 237-09_v2 4-37
MLC165-1 OPERATOR MANUAL SETUP AND INSTALLATION
Install Crane Counterweight
See Figure 4-31.
1. If not already done, install the carbody counterweight.
2. Disconnect the handling chains (3, View A) from the tie-
down lugs (8).
3. Disconnect the shackles (2, View A) from the storage
lugs (1) and allow the handling chains (3) to hang freely.
4. Remove the outer connecting pins (4, View A) from both
sides of the rotating bed. Put the pins on the
counterweight tray (6) for access later.
5. Start the engine.
6. Turn on the remote control icon (I) in the setup function
screen of the main display (see Setup Mode on page 4-
6).
7. Using the switch on the remote control, disengage the
inner connecting pins (5, View C) from both sides of the
rotating bed.
8. Position the crane (View B) in line with the
counterweight tray (6). A signal person is required to
direct the operator.
9. The handling chains (3, View B) must hang vertically
from side-to-side and front-to-rear in-line with the lifting
links (7), View B).
Continued on the next page.
DANGER
Tipping Hazard!
To prevent tipping or structural failure of components:
• Install the carbody counterweight before installing the
crane counterweight.
Crush Hazard!
To prevent serious crushing injury:
• Do not stand on, under, or in front of the crane
counterweight while it is lifted.
WARNING
Moving Equipment Hazard!
Before raising the counterweight tray, make sure the
handling chains are hanging vertical from side-to-side and
front-to-back.
Failure to do so may result in injury caused by the
counterweight swinging as it is lifted off the ground.
To Next Page
