SETUP AND INSTALLATION MLC165-1 OPERATOR MANUAL
4-36
Published 08-06-19, Control # 237-09_v2
Figure 4-31
NOTE: For clarity, the counterweight boxes are not shown.
View A
View B
Item Description
1 Storage Lug (2)
2 Shackle (4)
3 Handling Chain (4)
4 Outer Connecting Pin with Safety Pin (4)
5 Inner Connecting Pin (2)
6 Counterweight Tray
7 Lifting Link (2)
8 Tie-Down Lugs
View C
