SETUP AND INSTALLATION MLC165-1 OPERATOR MANUAL
4-2
Published 08-06-19, Control # 237-09_v2
ASSEMBLY AND DISASSEMBLY AREA
Select an assembly/disassembly area that has a firm, level,
uniformly supporting surface. Make sure the area is large
enough to accommodate the crane and the selected boom
length, the movement of trucks with trailers, and movement
of the assist crane.
Contact your Manitowoc dealer for ground bearing
information.
ACCESSING PARTS
Some parts of the crane, boom, and jib cannot be reached
from the ground. Take the necessary precautions to prevent
slipping and/or falling off the crane or boom during assembly
disassembly, maintenance, or other work.
CRANE WEIGHTS AND SHIPPING DATA
See Crane Weights topic in Section 1 of this manual for the
weights of individual crane components.
See the MLC165-1 Product Guide in Section 1 of this manual
for the outline dimensions of individual components and for
transport data. Size the transport trailers accordingly.
RETAINING CONNECTING PINS
Connecting pins are retained in various ways:
• Snap pins
• Quick-release pins
• Cotter pins
• Keeper plates with cap screws and lock washers
Do not operate the crane until all connecting pins are
installed and properly retained.
PARTS BOXES
Manitowoc provides two parts boxes: one for the crane and
one for the luffing jib. The parts boxes can be lifted with a
forklift.
The following types of parts are shipped in the parts box for
the crane:
• Boom butt shims
• Intermediate suspension parts
• Lower boom point 3-sheave center bolt
• Crawler adjusting parts
• Block-up limit parts
• Wind speed transmitter parts
• Wrench for -24 hydraulic coupler
• Quick-drain drainer valve (for changing oil)
• Position indicator light parts
• Wedge sockets, links, and pins
• Fixed jib links and pins
• Shore power plug and receptacle
• Mast-to-boom link pins (can be used to replace the load
sensing pins for duty-cycle operation) (see RCL/RCI
Operation Manual for details)
Carefully inventory the parts boxes according to the packing
diagrams under each parts box cover.
PIN AND CONNECTING HOLE
CLEANLINESS
To prevent dirt from damaging closely machined surfaces of
pins and connecting holes:
• Thoroughly clean all pins and connecting holes.
• Apply a light coat of grease to all pins and connecting
holes.
WARNING
Fall Hazard!
To avoid serious injury:
Falling from any height could result in serious injury or
death. The crane owner/user shall provide workers with
approved ladders or aerial work platforms to access those
areas of the crane, the mast, and the boom that cannot be
reached from the ground or from Manitowoc-provided
steps, ladders, catwalks, and platforms.
Adhere to local, state, and federal regulations for personal
fall protection.
