SETUP AND INSTALLATION MLC165-1 OPERATOR MANUAL
4-54
Published 08-06-19, Control # 237-09_v2
Figure 4-45
View A
View D
Item Description
1 Hitch Pin with Hair-Pin Cotter (2)
2 Outer Strut Frame
3 Inner Strut Frame
4 Hitch Pin with Hair-Pin Cotter (2)
5 Bracket (2)
A Pin here for 236.2 ft (72 m), 246.1 ft (75 m), and 255.9 ft (78 m) Boom
B Pin here for 265.7 ft (81 m) and 275.6 ft (84 m) Boom
View C
View B
