Manitowoc MLC165-1 User Manual

SETUP AND INSTALLATION MLC165-1 OPERATOR MANUAL
4-122
Published 08-06-19, Control # 237-09_v2
Rope
Clips
P1519
Wire Rope
without Button
Rigging
Line
Figure 4-96
M100461
M100462
M100463
Pad
Eye
Wire Rope
from Drum
Pad
Eye
Rigging
Line
Load Block Sheaves
EXAMPLE
Boom Point
Sheaves
Pull Rigging Line
with Winch or
Fork-Lift Truck
Wire
Rope
Wire Rope
with Button
Pad
Eye
Connector
OR
B
D
E
G
C
A
F
No. 1.5 Pad Eye Item Inch mm
Approximate Capacity 1220 lbs. (553 kg) A 5/8 16,00
B 1/4 6,35
C125,40
D 7/16 11,18
E 1-1/8 28,70
F1/164,06
G1-5/1633,27
No. 1 Pad Eye Item Inch mm
Approximate Capacity 1220 lbs. (553 kg) A3/89,65
B1/46,35
C 7/8 22,40
D 13/32 10,40
E 7/8 22,40
F1/83,30
G 1-1/32 25,40
No. 2 Pad Eye Item Inch mm
Approximate Capacity 2600 lbs. (1179 kg) A 3/4 19,05
B 3/8 9,65
C 1-1/16 26,92
D 1/2 12,70
E 1-1/2 38,10
F 3/16 4,83
G 1-5/8 41,26
B
