88F6281

Hardware Specifications

Page 104 Document Classification: Proprietary Information December 2, 2008, Preliminary

8.6.8.2 TWSI Test Circuit

Figure 24: TWSI Test Circuit

8.6.8.3 TWSI AC Timing Diagrams

Figure 25: TWSI Output Delay AC Timing Diagram

Figure 26: TWSI Input AC Timing Diagram

VDDIO

Test Point

SCK

SDA

Vih(min)

Vil(max)

Vih(min)

Vil(max)

tHIGH tLOW

tOV(max)

tOV(min)

Vih(min)

Vil(max)

Vih(min)

Vil(max)

tSU

tLOW tHIGH

SCK

SDA

tHD
