88F6281

Hardware Specifications

Page 32 Document Classification: Proprietary Information December 2, 2008, Preliminary

1.2.7 Serial Management Interface (SMI) Interface Pin

Assignments

Table 9: Serial Management Interface (SMI) Pin Assignments

Pin Name I/O Pin

Type

Power

Rail

Description

GE_MDC t/s

CMOS/ VDD_GE_A Management Data Clock

MDC is derived from TCLK divided by 128.

Provides the timing reference for the transfer of the MDIO signal.

GE_MDIO t/s

I/O

CMOS VDD_GE_A Management Data In/Out

Used to transfer control and status information between PHY

devices and the GbE controller.

NOTE: An external pullup is required.
