Electrical Specifications
DC Electrical Specifications
Copyright © 2008 Marvell Doc. No. MV-S104859-U0 Rev. E
December 2, 2008, Preliminary Document Classification: Proprietary Information Page 85
8.5.6 Time Division Multiplexing (TDM) 3.3V DC Electrical
Specifications
In the following table VDDIO means the either the VDDO or the VDD_GE_B power rail, depending
on which MPP pins are configured for the TDM interface.
Table 44: TDM Interface 3.3V DC Electrical Specifications
Parameter Symbol Test Condition Min Typ Max Units Notes
Input low level VIL -0.5 0.3*VDDIO V -
Input high level VIH 0.7*VDDIO VDDIO+0.5 V -
Output low level VOL IOL = 4 mA - 0.4 V -
Output high level VOH IOH = -4 mA VDDIO-0.6 - V -
Input leakage current IIL 0 < VIN < VDDIO -10 10 uA 1, 2
Pin capacitance Cpin 5 pF -
Note s:
General comment: See the Pin Description section for internal pullup/pulldow n.
1. While I/O is in High-Z.
2. This current does not include the current flow ing through the pullup/pulldow n resistor.
