Marvell Integrated Controller 88F6281 - Figure 40: Transport Stream Interface Test Circuit; Figure 41: Transport Stream Output Interface AC Timing Diagram

88F6281
Hardware Specifications
Doc. No. MV-S104859-U0 Rev. E Copyright © 2008 Marvell
Page 116 Document Classification: Proprietary Information December 2, 2008, Preliminary
8.6.14.2 Transport Stream Interface Test Circuit
Figure 40: Transport Stream Interface Test Circuit
8.6.14.3 Transport Stream Interface Timing Diagrams
Figure 41: Transport Stream Output Interface AC Timing Diagram
CL
Test Point
tOV(min)
Clock
Data Out
Vih(min)
Vil(max)
Vih(min)
Vil(max)
tOV(max)
tHIGH tLOW
