8 Electrical Specifications (Preliminary)
8.1 Absolute Maximum Ratings
Note
The numbers specified in this section are PRELIMINARY and SUBJECT TO CHANGE.
Table 35: Absolute Maximum Ratings
Parameter Min Max Units Comments
VDD -0.5 1.2 V Core voltage
VDD_CPU -0.5 1.32 V CPU interface
CPU_PLL_AVDD
CORE_PLL_AVDD
-0.5 2.2 V Analog supply for the internal PLL
SSCG_AVDD -0.5 2.2 V Analog supply for:
Internal Spread Spectrum Clock Generator
VDD_GE_A
VDD_GE_B
-0.5 4.0 V I/O voltage for:
RGMII/GMII/MII/MMII/SMI interface
VDD_M -0.5 2.2 V I/O voltage for:
SDRAM interface
VDDO -0.5 4.0 V I/O voltage for:
MPP, TWSI, JTAG, SDIO, I
2
S, SPI, TS, and
TDM interfaces
VHV -0.5 3.0 V I/O voltage for eFuse burning
PEX_AVDD -0.5 2.2 V Analog supply for:
PCI Express interface
USB_AVDD -0.5 4.0 V Analog supply for:
USB interface
SATA0_AVDD
SATA1_AVDD
-0.5 4.0 V Analog supply for:
SATA interface
XTAL_AVDD -0.5 2.2 V Analog supply for internal clock inverter for
crystal support and current source for SATA and
USB PHYs
