88F6281
Hardware Specifications
Doc. No. MV-S104859-U0 Rev. E Copyright © 2008 Marvell
Page 44 Document Classification: Proprietary Information December 2, 2008, Preliminary
TDM_SPI_MOSI O CMOS VDDO/
VDD_GE_B
Serial SPI data from the host to the codec for register access.
When TDM_SPI_CS is asserted low, the data is driven from the
host on the negative edge of TDM_SPI_SCK. It is always driven
for eight TDM_SPI_SCK cycles at a time.
In a byte, the data can be driven MSB or LSB first.
TDM_SPI_MISO I CMOS VDDO/
VDD_GE_B
Serial SPI read data from the CODEC to the host for register
access.
When TDM_SPI_CS is asserted low, this data is driven from
CODEC on negative edge of TDM_SPI_SCK. It is always driven
for eight TDM_SPI_SCK cycles at a time. The CODEC drives
data on this line only for a read operation, when it gets command
and address in previous bytes from the host on TDM_SPI_MOSI
In a byte, the data can be driven MSB or LSB first.
Table 20: Time Division Multiplexing (TDM) Interface Signal Assignment (Continued)
Pin Name
I/O
Pin Type Power Rail
Description
