TSMP[7] I/O CMOS VDDO/
VDD_GE_B
• Parallel Mode:
TS0_DATA[2]: Port0 TS Data bit 2
• Serial Mode:
TS1_SYNC: Port1 Sync/Frame Start Indicator or Packet
Clock.
The TS1_SYNC pulse may be active for the entire byte or
only for the first bit. The polarity is programmable to be either
active high or active low
TSMP[8] I/O CMOS VDDO/
VDD_GE_B
• Parallel Mode:
TS0_DATA[3]: Port0 TS Data bit 3
• Serial Mode:
TS1_VAL: Port1Valid Data Indicator
When this signal is used and is valid, it indicates that valid
data is present on TS1_DATA[0].
TS1_VAL is active during the TS frame packet data and
inactive when there is no TS synchronization.
In output mode, the polarity of TS1_VAL is programmable to
be either active high or active low.
TSMP[9] I/O CMOS VDDO/
VDD_GE_B
• Parallel Mode:
TS0_DATA[4]: Port0 TS Data bit 4
• Serial Mode:
TS1_ERR: Port1 Uncorrectable Packet Error
When this signal is used, an error indicates that the packet
contains an uncorrectable error, and, therefore, should not
be used.
In output mode the TS1_ERR is active during the entire TS
frame.
TSMP[10] I/O CMOS VDDO/
VDD_GE_B
• Parallel Mode:
TS0_DATA[5]: Port0 TS Data bit 5
• Serial Mode:
TS1_DATA[0]: Port1 TS Data bit 0, used as data input or
output.
TSMP[11] I/O CMOS VDDO/
VDD_GE_B
TS0_DATA[6]
Port0 TS Data bit 6
This pin is only valid in Parallel mode.
TSMP[12] I/O CMOS VDDO/
VDD_GE_B
TS0_DATA[7]
Port0 TS Data bit 7
This pin is only valid in Parallel mode.
Table 21: Transport Stream (TS) Interface Signal Assignment (Continued)
