Marvell Integrated Controller 88F6281

To Next Page

To Previous Page

88F6281

Hardware Specifications

Page 78 Document Classification: Proprietary Information December 2, 2008, Preliminary

XTAL_AVDD 1.7 1.8 1.9 V Analog supply for:

Internal clock inverter for crystal

support and current source for

SATA and USB PHYs

RTC_AVDD 1.7 1.8 1.9 V Analog supply for RTC in Regular

mode

1.3 1.5 1.7 V Analog supply for RTC in Battery

Back-up mode

TJ 0 105 ° C Junction Temperature

Table 36: Recommended Operating Conditions (Continued)

Parameter Min Typ Max Units Comments

Caution

Operation beyond the recommended operating conditions is neither recommended nor

guaranteed.
