Remove the plastic covers (6) located at the two input opening on the baling room to
center the piston horizontally. Turn the flywheel manually until you see piston horizontal
wheel bearing (7) bolts (8) from the input openings. Loosen horizontal wheel bearings that
are visible from input openings and touch them against L twist rails (9) and tighten using
socket wrench. (Figure 6.7.8)
Figure 6
Figure 7
