Matrox Display Wall – User Guide 11
Getting started
Thank you for purchasing a Matrox Display Wall product. You can use Matrox Mura IPX Series, Mura
MPX Series, and C-Series cards as standalone solutions, combined with eath other, or with third-
party
*
hardware to extend the capabilities of your Matrox-based display wall controller.
Hardware supplied
†
Mura IPX Series
–
Mura IPX 4K Quad SDI Capture and IP Encode/Decode
(MURAIPXI-E4SF • MURAIPXI-
E4SHF)
– Mura IXP Series card, 2 ribbon cables
‡
(for framelock).
Mura IPX 4K IP Decode and Display
(MURAIPXO-D4LF • MURAIPXO-D4LHF)
– Mura IPX
Series
card, 2 ribbon cables
‡
(for framelock).
Mura IPX 4K DisplayPort Capture and IP Decode
(MURAIPXI-D2MF • MURAIPXI-
D2MHF)
– Mura IPX Series card, 2 ribbon cables
‡
(for framelock).
Mura IPX 4K HDMI Capture and IP Encode/Decode
(MURAIPXI-E4JF • MURAIPXI-
E4JHF)
– Mura IPX
Series
card, 2 ribbon cables
‡
(for framelock).
Mura IPX 4K HDMI Capture and IP Decode
(MURAIPXI-D4JF • MURAIPXI-D4JHF)
–
Mura IPX
Series
card, 2 ribbon cables
‡
(for framelock).
Mura IPX 4K DisplayPort Capture and IP Encode/Decode
(MURAIPXI-E2MF •
MURAIPXI-E2MHF)
– Mura IPX Series card, 2 ribbon cables
‡
(for framelock).
Matrox C-Series
–
C900
– C-Series graphics card.
C680
– C-Series graphics card.
Mura MPX Series
–
Mura MPX-4/4 –
Mura MPX
Series
card, 2 KX20 to quad-DVI cables, 8 DVI to HD-15
adapters, 2 ribbon cables (for framelock), washer.
Mura MPX-4/2 –
Mura MPX
Series
card, 1 KX20 to quad-DVI cable, 1 KX20 to dual-
DVI cable, 6 DVI to HD-15 adapters, 2 ribbon cables (for framelock), washer.
* For more information on supported third-party graphics cards, see the release notes. For information on how to configure your
system, see “Matrox System Builder’s Guide.”
† The hardware supplied with your Matrox product may vary depending on the SKU or part number of your product. For more
information, contact your Matrox representative.
‡ Matrox Mura IPX Series – The ribbon cables (for framelock) are currently unsupported.
