Matrox C Series - Mura MPX-4;0; Connection Overview

To Next Page

To Previous Page

Matrox Display Wall – User Guide 43

Mura MPX-4/0

This section describes how to connect your output devices (monitors) to your Mura MPX-4/0 card.

Connection overview

Monitor

connector

(HD-15)

Monitor

connector

(DVI)

Output cable

(KX20 to Quad-DVI)

DVI to HD-15

adapter
