Matrox C Series - Mura MPX-4;4 and MPX-4;2; Connection Overview

Matrox Display Wall – User Guide 39
Mura MPX-4/4 and MPX-4/2
This section describes how to connect your output devices (monitors) and input devices to your Mura
MPX-4/4, and MPX-4/2 cards.
Connection overview
Input cables
(KX20 to Quad-DVI or Dual-DVI)
Component
video cable
Composite
video cable
(RCA)
S-video
cable
Monitor
connector
(HD-15)
Monitor
connector
(DVI)
Monitor
connector
(HD-15)
Monitor
connector
(DVI)
Output cable
(KX20 to
Quad-DVI)
