Matrox C Series - Mura IPX Series 4 K Decode and Display Card

62 Matrox Display Wall – User Guide
Mura IPX Series 4K Decode and Display card
MURAIPXO-D4LF • MURAIPXO-D4LHF
Operating systems supported —
*
* A Mura IPX Series display card is a standalone controller that doesn’t require an operating system.
Card type PCIe ×8 2.0 (power only)
Form factor ATX
Memory 4 GB
Connectors 4× Mini DisplayPort, 1× 100/1000 Base-T RJ45 Ethernet Port
Output formats supported
†
† DVI and HDMI monitors are supported using identical third-party active adapters (sold separately).
DisplayPort, DVI, HDMI
Outputs supported 4
Inputs supported IP
Maximum output resolutions
4096 × 2160 @ 30 Hz,
3840 × 2160 @ 30 Hz,
2560 × 600 @ 60 Hz
IP stream support RTSP, RTP, SRT, MPEG-2 TS
Video CODEC engine H.264
Audio stream support 9
H.264 decode
‡
‡ Standard resolutions listed above. Support for custom resolutions available. For specific requirements, contact your Matrox
representative.
two 3840 × 2160 @ 60 Hz, four 3840 × 2160 @ 30 Hz,
eight 1920 × 1080 @ 60 Hz, sixteen 1920 × 1080 @ 30 Hz,
or numerous SD channels
Maximum card dimensions
L: 9.02 in / W: 0.75 in / H: 4.376 in
L: 22.9 cm / W: 1.91 cm / H: 11.1 cm
Regulatory compliance Class B: FCC, CE, RCM, VCCI, ICES-3, CSA, KC
